| Place of Origin: | China |
| Brand Name: | Crystal Base |
| Certification: | CE/CSI/BS/ASTM |
| Model Number: | TSG |
| Minimum Order Quantity: | 100sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in Strong Plywood Crates or Cases with PE,paper or Saftpad interlayer |
| Delivery Time: | 15 days after order confirmed |
| Payment Terms: | T/T ,L/C,DP or western Union |
| Supply Ability: | 3,000 Sqm per Day |
| Product Name: | Tempered Safety Glass | Application: | -Windows Of Motor Vehicles, Boats And Ships |
|---|---|---|---|
| Size Of Panel: | Various | Colours: | Clear |
| Standard: | CE/CSI/BS/ASTM | Type: | Curved Sheet Glass |
| Thickness: | 3mm,4mm, 5mm, 6mm, 8mm | Transmittance: | More Than 88% |
| Softening Temperature: | 650 ~ 700 ° | ||
| High Light: | tempered float glass,toughened safety glass |
||
Powder Coating Finished Tempered Safety Glass Aluminum Casement Windows
Description:
The glass is raised to softening temperature (650°C) and is then cooled suddenly. Toughened glass is also a type of safety glass, five times stronger than normal glass.
Specification
| Max. size of flat tempered glass | 4-8mm: 2400×3600mm 10-12mm: 2400*4200mm 15-19mm:2400*4500mm |
| Thickness | 3mm,4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 15mm,19mm, etc. |
| Color | Clear, Ultra clear; Euro bronze, golden bronze; Blue, ocean blue, dark blue, light blue; F green, light green, dark green; Euro Grey, dark Grey. |
Application of clear tempered glass
|
Features:
Safety: Glass is not easy to be broken when attacked. Broken glass particle is of honeycomb shape with obtuse angles which won’t cause serve hurt to human body.
High Mechanical-resistant strength: Impact-resistant strength of tempered glass is 3-5 times higher than that of float glass of the same thickness.
Thermal stability: Thermal stability of tempered glass is 3 times higher than that of float glass of same thickness. Tempered glass can withstand sudden temperature shift of 220-250 degree while float glass can only withstand shift of 70-100 degree.
Good flexibility: Deflection angle of tempered glass is 3-4 times larger than that of float glass of the same thickness. When there is load on tempered glass, its maximum tensile stress does not locate on the glass surface as float glass, but on the centre point of glass sheet.
