6.38mm Decorative Laminated Glass Offers Multi-color , Euro Grey Float Tempered Glass

Product Details:

Place of Origin:	China
Brand Name:	Crystal Base
Certification:	CE/CSI/BS/ASTM
Model Number:	TSG

Payment & Shipping Terms:

Minimum Order Quantity:	100sqm
Price:	negotiation
Packaging Details:	Packed in Strong Plywood Crates or Cases with PE,paper or Saftpad interlayer
Delivery Time:	15 days after order confirmed
Payment Terms:	T/T ,L/C,DP or western Union
Supply Ability:	3,000 Sqm per Day

Contact Now

Detailed Product Description

Product Name:	Laminated Safety Glass	Application:	Automatic Arm Rest, Balcony Windows And Doors, Glass Partition, Stadium,
Size Of Panel:	Various	Standard:	CE/CSI/BS/ASTM
Type:	Float Glass	Thickness:	1.14mm,1.52mm,1.9mm,2.28mm
Transmittance:	More Than 88%	Technique:	Tinted Glass
Color:	Golden Bronze;Blue, Ocean Blue
High Light:	safety toughened glass , laminated glass door

6.38mm Laminated Glass Offers multi-color , Euro Grey Float Tempered Glass

Specification

6.38mm Laminated Glass offers multi-color for options, because PVB film has different colors, such as: blue, milky white, red, green, brown, black, yellow, purple, etc.

Different glass combinations are availabe, for example:

1. 3mm/ 4mm/5mm/6mm/8mm/10mm/12mm/15mm/19mm clear float glass+0.38mm colored pvb film+ 3mm/ 4mm/5mm/6mm/8mm/10mm/12mm/15mm/19mm clear float glass;

2. 4mm/5mm/6mm tinted float glass+0.38mm transparent pvb film+ 4mm/5mm/6mm clear float glass;

Glass thickness 3mm, 4mm, 5mm, 5.5mm, 6mm, 8mm, 10mm, 12mm, 19mm, 20mm,22mm, etc.

Glass Thickness		3mm,4mm,5mm,6mm,8mm,10mm,12mm,15mm,19mm.22mm
PVB Tickness (laminated tempered glass)		0.38mm,0.76mm,1.14mm,1.52mm,1.9mm,2.28mm
Size	Minimum Size	300mm×300mm
	Maximum Size	2440mm×5000mm
Color of tempered glass fence panels		Clear, Ultra Clear, Grey, Light Grey, Euro Grey, Green, F-green, Blue, Dark Blue, Ocean Blue, etc.
Specifications of tempered glass fence panels		Clear float tempered glass, reflective tempered glass, tinted tempered glass, low-E tempered glass, tempered pattern glass, silk screen printed tempered glass.

Applications:The tempered glass is mainly used in the glass curtain wall, large display window, bathroom, automatic

arm rest, balcony windows and doors, glass partition, stadium, the buildings where there is a large

crowd and the damage easily happens due to human body’s easy touching.

Description

Laminated glass is a sandwich made of one piece of plastic Poly Vinyl Butyral between two or more glasses. The PVB sticks with the glass, forms chemical as well as mechanical bonds. When laminated with annealed glass, the layer maintains the geometric integrity of the pane in case of breakage. Also it gives acoustic insulation as well as gives protection against damage caused due to UV radiation because it cuts almost 99% of UV radiation present in the sunlight. A Laminated glass is regarded as a safety glass by most of the standards.

Features:
