8mm Flat Tempered Glass Pool Fencing , Splashback Glass Handrails

8mm Flat Tempered Glass Pool Fencing , Splashback Glass Handrails

    • 8mm Flat Tempered Glass Pool Fencing , Splashback Glass Handrails
    • 8mm Flat Tempered Glass Pool Fencing , Splashback Glass Handrails
  • 8mm Flat Tempered Glass Pool Fencing , Splashback Glass Handrails

    Product Details:

    Place of Origin: China
    Brand Name: Crystal Base
    Certification: CE/CSI/BS/ASTM
    Model Number: TSG

    Payment & Shipping Terms:

    Minimum Order Quantity: 100sqm
    Price: negotiation
    Packaging Details: Packed in Strong Plywood Crates or Cases with PE,paper or Saftpad interlayer
    Delivery Time: 15 days after order confirmed
    Payment Terms: T/T ,L/C,DP or western Union
    Supply Ability: 3,000 Sqm per Day
    Contact Now
    Detailed Product Description
    Product Name: Glass Pool Fencing Application: Balustrade, Stair, Partition, Splashback, Pool Fence,
    Size Of Panel: Various Colours: Clear Or Light Green
    Standard: CE/CSI/BS/ASTM Type: Flat Or Curved Sheet Glass
    Thickness: 8-12mm Transmittance: More Than 88%
    Softening Temperature: 650 ~ 700 °
    High Light:

    tempered glass fence panels

    ,

    glass swimming pool fence

    8mm Flat Tempered Glass Pool Fencing , Splashback Glass Handrails





    1. Brief Introduction

    Toughened glass(Tempered glass) is made by heating flat glass to just below its softening temperature and suddenly chilling it with jets of cold air. It results the outer skins under powerful compressive stress and the interior with severe tensile stress. In consequence, the impact applied to the glass will be overcome by the compressional stress on the surfaces to assure safety of use





    2. Details Information


    Product

    Tempered Glass

    Other Name

    Toughened Glass

    Specification

    Flat Tempered Glass
    Max size 3660mm*2800mm
    Min size 100mm*100mm


    Curved Tempered Glass
    Min curved radius 550mm
    Arc of length: Max 2400mm Min300mm
    Height: Max 3660mm   Min300mm

    Authentication

    CCC ;
    GB/T19001-200idtISO9001:2000;
    AS/NZS 2208:1996

    Usage

    Glass Door & Window, Balustrade, Stair, Partition, Splashback, Pool fence, Curtain Wall, Showcase, Shower, Cabinet, Furniture, Canopy, etc



    Thickness

    Container

    1X20GP

    1X40GP

    1X40HQ

    Loading capacity

    18T

    22T

    22T

    Kg/m²

    Square meter

    Square meter

    Square meter

    3mm

    7.5

    2400

    2900

    2900

    4mm

    10

    1800

    2200

    2200

    5mm

    12.5

    1440

    1760

    1760

    6mm

    15

    1200

    1470

    1470

    8mm

    20

    900

    1100

    1100

    10mm

    25

    720

    880

    880

    12mm

    30

    600

    730

    730

    15mm

    37.5

    480

    580

    580

    19mm

    47.5

    380

    460

    460

    Note

    All the above data is just for your reference






    3. Advantages

    1). No tong marks on the glass as  adopts the horizontally tempering process.
    2). 5 times harder than ordinary annealed glass.
    3). Once breakage occurs, the glass disintegrates into small cubical fragments which are relatively armless to human body.
    4). It withstands abrupt change of temperature. For example, a piece of 5mm tolerate the temperature variations within the range of 200°C.



    4. Product Quality


    1). Conforming to ASTM1048, ANSI Z97.1 , the American standard
    2). Conforming to BS6206, the British standard
    3). Conforming to GB 15763.2,GB17841 , 3C the Chinese standard.
    4). Australia AS/NZS 2208 certification
    5). SGCC certification
